CX-33 Advanced Logic Relay

CX-33-Advanced Logic Relay CX-33 Advanced Logic Relay is a 'state of the art' door controller designed for 'Universal' operation in virtually any automatic door application. It features 15 operation modes, with sub-modes and easy programming with large LCD display and push button selection.

Camden's CX-33 is a 'state of the art' logic relay designed to support virtually any automatic door application. The CX-33 features 15 operating modes, with sub-modes, and easy programming with large LCD display and push button selection.

Applications: Programmable modes include up to 3 door sequencing, airlocks, lock-out-relay, fire door in stairwells, and for control of automatic operators in restroom applications, with support of illuminated indicator of occupancy status.

New Version 3.2 Features:
'Lock Down' Mode will enable a designated (N/O) momentary switch to disable door activation switches and simultaneously lock strikes/mag locks. Reset with separate (N/O) switch.
'Delayed Relay' Mode will immediately activate relay #1 and delay relays #2 and #3 for a pre-set time.
Selectable Input Types allows dry and wet inputs to accept either a normally open or a normally closed contact.

Features
Ideal for most automatic door applications, as well as air lock and other security applications.
15 operating modes, with sub-modes. Selection and configuration with 3 push buttons
Easily sequence multiple inputs with multiple maintain and hold outputs.
Large 3 segment (blue) LED display
Selectable time delays, with delay on input activation
‘Tried and true’ power circuitry ensures outstanding power filtering and surge protection.
Larger terminal strips allow larger wire gauge, or more conductors to be connected.
Clear plastic case provides better protection of circuit board and easy mounting.
12/24V AC/DC
3 year warranty
Specifications
Voltage: 12 to 30V AC/DC
Current Draw: 105 mA Typical, 320 mA Maximum
Response Time: .5 Seconds
Display: Blue LED: 1 Alpha/Numeric and 2 x 7-Segment
Input: 4 x Dry
1 x Wet: min. 4.5V AC/DC
Output: 3 x Form C (SPDT)
Contact Rating: 3 A @ 24 VDC
Temp Range: -22°F to +185°F (-30°C to +85°C)
Electrical Life: 100,000 Operations @ Rated Capacity
Time Delay: Hold 1 timer: 0-50 Seconds
Delay 1 Timer: 0-15 Seconds
Hold 2 timer: 0-50 Seconds
Delay 2 timer: 0-60 Seconds
Hold 3 Timer: 0-50 Seconds
Delay on Activate: 0-10 Seconds
Dimensions: 2"L x 6"W x 7/8"H
(51mm x 152mm x 22mm)
Mounting: 2 x #6 Screws or Velcro
Installation Manuals
CX-33_Manual_English_R5
CX-33_Manual_French_R5

Models
CX-33 Advanced Logic Relay
