CM-74/75 & CM-84/85 Series Column™ Push Plate Switches
|
|
CM-75 Series Column™ ADA compliant push plate switches are easy to install (wired or wireless), easy to activate (from any angle) and provide years of trouble free operation.
Column™ switches now available with Hands Free Sensor!
|
|
|
|
|
PAGE IS UNDER CONSTRUCTION. PLEASE CONTACT CUSTOMER SERVICE FOR ASSISTANCE.
TOP LOAD: 4.5" WIDE - CM-74 SERIES & 6" WIDE - CM-75 SERIES 'Top Load' Column™ push plate switches are surface-mounted and designed for use when there is no obstruction above the installed unit, and a very low profile is desired.
SIDE LOAD: 4.5" WIDE - CM-84 SERIES & 6" WIDE - CM-85 SERIES 'Side Load' Column™ push plate switches feature a two-piece construction with a surface-mount back box and are designed for use when an obstruction above the installed unit prevents the installation of a 'Top Load' model, where the Column™ switch is mounted to narrow curtain-wall, or where the Column™ switch will span a lite of glass.
|
|
|
|
|
| • |
OBC, NBC, & CSA compliant. 1-1/2" (12.7mm) deep
(Stainless Steel model not CSA compliant)
|
| • |
2-1/4" (32mm) deep with CSA compliant activation plate
|
| • |
Option for built-in touchless activation sensor
|
| • |
Option for Kinetic™ or Lazerpoint wireless
|
| • |
Surface mount with leveling screws (no back box)
|
| • |
Heavy-duty extruded aluminum construction
|
| • |
Option for built-in touchless activation sensor
|
| • |
Option for Kinetic™ or Lazerpoint wireless
|
| • |
Option for DPDT switches
|
| • |
Surface mount with integral back box
|
|
|
| Voltage: |
N/A |
| Voltage: |
12-24 VDC +/- 10% |
| Contact Rating: |
15 Amps @ 30 VDC |
| Contact Type: |
SPDT Momentary, Form 'C'
Optional DPDT Switch Used With CM-84 & 85 Series |
| Contact Rating: |
1 Amp @ 30 VDC |
| Contact Type: |
Common / N.O. / N.C.
Optional DPDT Switch Used With CM-84 & 85 Series |
|
|
|
|
|
TOP LOAD MODELS
|
4.5" Wide
|
| CM-7436 |
 |
36" x 4.5" Column™ aluminum push plate switch, anodized clear finish
|
|
| CM-7436VR |
|
36" x 4.5" Column™ aluminum push plate switch with hands-free sensor, anodized clear finish
|
|
| CM-7436K |
|
36" x 4.5" Column™ aluminum push plate switch, anodized clear finish with built-in Kinetic no-battery wireless transmitter, receiver required
|
|
6" Wide
|
| CM-7536 |
|
36" x 6" Column™ aluminum push plate switch, anodized clear finish
|
|
| CM-7536VR |
|
36" x 6" Column™ aluminum push plate switch with hands-free sensor, anodized clear finish
|
|
| CM-7536K |
|
36" x 6” Column™ aluminum push plate switch, anodized clear finish with built-in Kinetic no-battery wireless transmitter, receiver required
|
|
| CM-7536SS |
|
36"x 6" Column™ stainless steel push plate switch, brushed stainless steel finish
|
|
| CM-7536SSVR |
|
36" x 6" Column™ aluminum push plate switch with hands-free sensor, brushed stainless steel finish
|
|
| CM-7536SSK |
|
36" x 6” Column™ stainless steel push plate switch, brushed stainless steel finish with built-in Kinetic no-battery wireless transmitter, receiver required
|
|
SIDE LOAD models
|
4.5" Wide
|
| CM-8436 |
|
36" x 4.5" Column™ aluminum side load push plate switch, anodized clear finish
|
|
| CM-8436VR |
|
36" x 4.5" Column™ aluminum side load push plate switch with hands-free sensor, anodized clear finish
|
|
| CM-8436K |
|
36" x 4.5" Column™ aluminum side load push plate switch, anodized clear finish with built-in Kinetic no-battery wireless transmitter, receiver required
|
|
6" Wide
|
| CM-8536 |
|
36" x 6" Column™ aluminum side load push plate switch, anodized clear finish
|
|
| CM-8536VR |
|
36" x 6" Column™ aluminum side load push plate switch with hands-free sensor, anodized clear finish
|
|
| CM-8536K |
|
36" x 6” Column™ aluminum side load push plate switch, anodized clear finish with built-in Kinetic no-battery wireless transmitter, receiver required
|
|
|
|
 |
