CX-33 Advanced Logic Relay
|
|
CX-33 Advanced Logic Relay is a 'state of the art' door controller designed for 'Universal' operation in virtually any automatic door application. It features 15 operation modes, with sub-modes and easy programming with large LCD display and push button selection.
|
|
|
|
|
Camden's CX-33 is a 'state of the art' logic relay designed to support virtually any automatic door application. The CX-33 features 15 operating modes, with sub-modes, and easy programming with large LCD display and push button selection.
Applications: Programmable modes include up to 3 door sequencing, airlocks, lock-out-relay, fire door in stairwells, and for control of automatic operators in restroom applications, with support of illuminated indicator of occupancy status.
Camden's CX-33-PS metal cabinet includes a pre-wired CX-33 advanced logic relay and 2.5 Amp power supply, with the option for a cabinet lock.
|
|
|
|
|
| • |
Ideal for most automatic door applications, as well as air lock and other security applications.
|
| • |
Metal Cabinet w/ CX-33 and 2.5 Amp power supply available
|
| • |
15 operating modes, with sub-modes. Selection and configuration with 3 push buttons
|
| • |
Easily sequence multiple inputs with multiple maintain and hold outputs.
|
| • |
Large 3 segment (blue) LED display
|
| • |
Selectable time delays, with delay on input activation
|
| • |
‘Tried and true’ power circuitry ensures outstanding power filtering and surge protection.
|
| • |
Larger terminal strips allow larger wire gauge, or more conductors to be connected.
|
| • |
Clear plastic case provides better protection of circuit board and easy mounting.
|
| • |
12/24V AC/DC
|
| • |
3 year warranty
|
|
|
| Time Delay (Delay on Activate): |
0-10 Seconds |
| Voltage: |
12 to 30V AC/DC |
| Current Draw: |
105 mA Typical, 320 mA Maximum |
| Response Time: |
.5 Seconds |
| Display: |
Blue LED: 1 Alpha/Numeric and 2 x 7-Segment |
| Input: |
4 x Dry
1 x Wet: min. 4.5V AC/DC |
| Output: |
3 x Form C (SPDT) |
| Contact Rating: |
3 A @ 24 VDC |
| Temp Range: |
-22°F to +185°F (-30°C to +85°C) |
| Electrical Life: |
100,000 Operations @ Rated Capacity |
| Time Delay (Hold 1 timer): |
0-50 Seconds |
| Time Delay (Delay 1 Timer): |
0-15 Seconds |
| Time Delay (Hold 2 timer): |
0-50 Seconds |
| Time Delay (Delay 2 timer): |
0-60 Seconds |
| Time Delay (Hold 3 Timer): |
0-50 Seconds |
| Dimensions: |
2"L x 6"W x 7/8"H
(51mm x 152mm x 22mm) |
| Mounting: |
2 x #6 Screws or Velcro |
|
|
|
|
|
Models
| CX-33 |
 |
Advanced Logic Relay
|
|
| CX-33PS |
|
Advanced Logic Control Relay & Power Supply Cabinet
. . . more
Advanced Logic Control Relay & Power Supply Cabinet
. . .
Pre-wired for general door control applications. Order pre-wired cabinets for restroom control system kits separately. 60-40E032 for CX-WC11 Kit, 60-40E033 for CX-WC13 kit, 60-40E035 for CX-WC16 kit
. . . less
|
|
|
|
