CM-400 Series 1-5/8" Pushbutton, Stainless Steel Faceplate
|
|
CM-400 Mushroom push buttons are rugged and attractive request-to-exit buttons (REX) that feature 18 gauge stainless steel faceplates and a complete range of button sizes, button colors, activation types and contact options.
|
|
|
|
|
CM-400 Series mushroom push buttons are available in red, blue, or green (other colors on request), with a 1-5/8" (40mm) diameter. To protect against vandalism, the buttons are free-spinning. They are supplied with an industrial grade 18 gauge stainless steel faceplate.
|
|
|
|
|
| • |
1-5/8" (40mm) diameter button
|
| • |
Vandal resistant free-spinning, heavy-duty button
|
| • |
Vandal resistant 18 gauge stainless steel faceplate
|
| • |
Single gang, double gang and narrow faceplates
|
| • |
3 year warranty
|
|
|
| Voltage: |
12/24 VDC |
| Contact Rating: |
6 A @ 30 VDC |
| Std. Finish: |
US32 / C32D |
| Switch Type: |
Momentary |
| Dimensions: |
4-1/2"H x 2-3/4"W x 1-3/4"D
(114mm x 70mm x 44mm) |
| Dimensions: |
4-1/2"H x 1-3/4"W x 1-3/4"D
(114mm x 44mm x 44mm) |
| Dimensions: |
4-1/2"H x 4-1/2"W x 1-3/4"D
(114mm x 114mm x 44mm) |
|
|
|
|
|
Models
|
Single Gang Faceplate
|
| CM-400 |
 |
Single Gang, N/O contacts
|
|
| CM-410 |
|
Single gang, N/C contacts
|
|
| CM-420 |
|
Single gang, N/O and N/C contacts
|
|
| CM-450R |
|
Single gang, Push/Pull, N/O & N/C Stainless steel faceplate, maintained.
. . . more
Single gang, Push/Pull, N/O & N/C Stainless steel faceplate, maintained.
. . .
Red only button color. Optional graphics and finishes available (not shown in switch configuration wizard)
. . . less
|
|
| CM-420RPTE |
|
Single gang, N/O and N/C contacts, Red button, 'Push to Exit' engraved on button.
. . . more
Single gang, N/O and N/C contacts, Red button, 'Push to Exit' engraved on button.
. . .
No options or finishes on this model
. . . less
|
|
| CM-450RL-7724-CPC |
|
Single gang, Push/Pull N/O & N/C contacts heavy duty single gang stainless steel faceplate, red flashing 1/2” 24V LED and vandal resistant clear plastic lift cover
|
|
Narrow Faceplate
|
| CM-400N |
|
Narrow, N/O contacts
|
|
| CM-410N |
|
Narrow, N/C contacts
|
|
| CM-420N |
|
Narrow, N/O and N/C contacts
|
|
Double Gang Faceplate
|
| CM-400W |
|
Double gang, N/O contact
|
|
| CM-410W |
|
Double gang, N/C contact
|
|
| CM-420W |
|
Double gang, N/O and N/C contacts
|
|
|
|
