CX-ED1689L-4 & CX-ED1799L-8 'Universal' Low Profile & Dual Monitor Grade 1 Electric Strikes
|
|
Camden CX-ED1689L-4 and CX-ED1799L-8 Grade 1 electric strikes for mortise and cylindrical locksets offer the very best strike quality and features, with the added value of built-in single or dual latch monitoring, 4 or 8 stainless steel faceplates and 'Universal' performance, including field selectable voltage and fail safe/fail secure operation. These strikes also include a 3-hour fire rating, and also have the option of ordering strike bodies and individual faceplates separately.
|
|
|
|
|
Camden CX-ED1689L and CX-ED1799L Grade 1 electric strikes for mortise and cylindrical locksets offer the very best strike quality and features, with the added value of built-in single or dual latch monitoring, 4 or 8 stainless steel faceplates and 'Universal' performance, including field selectable voltage and fail safe/fail secure operation.
These strikes also include a 3-hour fire rating, and also have the option of ordering strike bodies and individual faceplates separately.
|
|
|
|
|
| • |
For mortise and cylindrical locksets
|
| • |
Selectable fail safe / fail secure
|
| • |
Selectable 12/24V AC/DC
|
| • |
1 or 2 latch and deadbolt monitoring switches
|
| • |
Magnetic door position switch
|
| • |
Strike power monitor
|
| • |
Easy fit connectors
|
| • |
5 year warranty
|
| • |
Low Profile, with latch monitoring
|
| • |
Low Profile strike w/ latch monitoring package includes 4 faceplates for latch bolts
|
| • |
Dual Monitor strike, with Latch monitoring
|
| • |
Dual monitor strike w/ latch monitoring package includes 8 faceplates for latch bolts and dead bolts
|
|
|
| Voltage: |
12/24V AC/DC |
| Current Draw: |
300mA @ 12V AC/DC
150mA @ 24V AC/DC |
| Static Strength: |
1,500 lbs |
| Dynamic Strength: |
70 ft-lbs |
| Endurance: |
1,500,000 Cycles (Factory Tested)
250,000 Cycles (UL Verified) |
| Mode: |
Field Selectable Fail Safe/Fail Secure |
| Operation: |
AC-Buzz, DC-Silent |
| Duty: |
Continuous |
| Lock Monitor Status: |
2 x SPST, 100mA @ 24V DC, Resistive |
| Strike Monitor Status: |
SPDT, 100mA @ 24V DC, Resistive |
| Dimensions (body): |
4-7/8''H x 1-5/8''W x 1-3/8''D
(124mm x 41mm x 36mm) |
| Dimensions (body): |
4-7/8''H x 1-5/8''W x 1-21/32''D
(124mm x 41mm x 42mm) |
|
|
|
|
|
Models
| CX-ED1689L |
 |
Low profile strike body with (1) latch monitor switch
. . . more
Low profile strike body with (1) latch monitor switch
. . .
Mortise strike low profile body only
. . . less
|
|
| CX-ED1799L |
|
Dual monitor strike body with (2) monitor switches
. . . more
Dual monitor strike body with (2) monitor switches
. . .
mortise strike body only
. . . less
|
|
Faceplate Packs
|
| CX-ED1689L-4 |
|
Low profile strike body with (1) latch monitor switch comes with 4 faceplates for latch bolts
. . . more
Low profile strike body with (1) latch monitor switch comes with 4 faceplates for latch bolts
. . .
Includes: CX-EMP100, CX-EMP200, CX-EMP300, CX-EMP400
. . . less
|
|
| CX-ED1799L-8 |
|
Dual monitor strike body with (2) monitor switches comes with 8 faceplates.
. . . more
Dual monitor strike body with (2) monitor switches comes with 8 faceplates.
. . .
Includes: CX-EMP100, CX-EMP200, CX-EMP300, CX-EMP400, CX-EMP110, CX-EMP210, CX-EMP310, CX-EMP410
. . . less
|
|
Faceplate Options
|
Wood Door Frame Stainless Steel Faceplates
|
| CX-EMP100W |
|
Wood frames, deadbolt used for night latch function only. Compatible with Marks, Omnia, PDQ, Arrow, Accurate locksets
|
|
| CX-EMP110W |
|
Wood frames, center line applications. Compatible with all cylindrical locksets
|
|
| CX-EMP400W |
|
Wood frames, dead latch positioned above the latch bolt. Compatible with all cylindrical locksets
|
|
Metal Door Frame Stainless Steel Faceplates
|
| CX-EMP100 |
|
'ANSI' square-metal door frame, center line applications. Compatible with all cylindrical locksets
|
|
| CX-EMP200 |
|
'ANSI' square-metal door frame, Deadlatch positioned above latchbolt. Compatible with Baldwin, PDQ, Marks locksets
|
|
| CX-EMP300 |
|
'ANSI' square-metal frame, deadlatch positioned above latch. Compatible with Sargent-8100/7700, Schlage, Yale 8700 locksets
|
|
| CX-EMP400 |
|
'ANSI' square-metal frame, deadlatch positioned below the latchbolt. Compatible with Corbin Russwin, Falcon, Sargent/7800 locksets
|
|
| CX-EMP110 |
|
'ANSI' square-metal frame, deadbolt used for night latch function only. Compatible with Marks, Omnia, PDQ, Arrow, Accurate locksets
|
|
| CX-EMP210 |
|
'ANSI' square-metal frame, deadlatch positioned below the latchbolt. Compatible with Corbin Russwin, Best-45/47, Falcon, Sargent-7800/ 8200/ 9200 locksets
|
|
| CX-EMP310 |
|
'ANSI' square-metal frame, deadbolt used for night latch function only. Compatible with Sargent-7700/ 8100, Yale 8700 locksets
|
|
| CX-EMP410 |
|
'ANSI' square-metal frame, used for 1" deadbolt and no latch. Compatible with Marks, Baldwin, Arrow, PDQ, Omnia locksets
|
|
Metal Door Frame All-Black Faceplates (BHMA 622, US19)
|
| CX-EMP100-BK |
|
'ANSI' square-metal door frame, center line applications. Compatible with all cylindrical locksets
|
|
| CX-EMP110-BK |
|
'ANSI' square-metal frame, deadbolt used for night latch function only. Compatible with Marks, Omnia, PDQ, Arrow, Accurate locksets
|
|
| CX-EMP200-BK |
|
'ANSI' square-metal door frame, Deadlatch positioned above latchbolt. Compatible with Baldwin, PDQ, Marks locksets
|
|
| CX-EMP210-BK |
|
'ANSI' square-metal frame, deadlatch positioned below the latchbolt. Compatible with Corbin Russwin, Best-45/47, Falcon, Sargent-7800/ 8200/ 9200 locksets
|
|
| CX-EMP300-BK |
|
'ANSI' square-metal frame, deadlatch positioned above latch. Compatible with Sargent-8100/7700, Schlage, Yale 8700 locksets
|
|
| CX-EMP310-BK |
|
'ANSI' square-metal frame, deadbolt used for night latch function only. Compatible with Sargent-7700/ 8100, Yale 8700 locksets
|
|
| CX-EMP400-BK |
|
'ANSI' square-metal frame, deadlatch positioned below the latchbolt. Compatible with Corbin Russwin, Falcon, Sargent/7800 locksets
|
|
| CX-EMP410-BK |
|
'ANSI' square-metal frame, used for 1" deadbolt and no latch. Compatible with Marks, Baldwin, Arrow, PDQ, Omnia locksets
|
|
|
|
